Braking Distance Simulator for Robotic Cells

Feb. 25, 2021
Offline programming suite now offers a virtual function to calculate robot stopping distances, to optimize operator safety and reduce robotic cell footprint by up to 25%.

ABB ROBOTICS' RobotStudio® offline programming and simulation software has been upgraded with a new, virtual robot braking-distance function designed to create an exact simulation of the real-world stopping distance of a robot. It makes it possible to calculate accurately the robot’s braking distance, and thereby to overcome the need to add safety margins into cell designs. As a result, plants and workshops may save up to 25% of required operating space.

Predicting exactly where a robot will stop depends on a range of variables, including speed, payload and the robot's own inertia. These factors, individually or combined, can result in the robot coming to a halt outside of its safety zone, sometimes by several meters. To compensate for the variability in stopping distances, engineers designing robot cells traditionally oversize them to allow for additional movement as the robot comes to a stop, which uses unnecessary space on the factory floor.

The new RobotStudio function uses ABB's motion-control technology to predict the robot's movements with millimetric precision. This allows the exact movement of the robot to be simulated in RobotStudio, so the user can determine the correct size of the safety zone required, and the ideal location of features including light curtains, safety fencing and controllers.

For applications using ABB's SafeMove software, the data on the robot's final position can be used to determine the size of the 'green,' 'amber' and 'red' zones where the robot either will continue working, slow down, or come to a halt, depending on the location of the operator. This is especially beneficial in collaborative applications where operators need to be confident that a robot has stopped before approaching it.

"Our new robot braking distance function for RobotStudio equips the user with information about a robot’s real-world movements with an unprecedented level of accuracy,” according to Antti Matinlauri, head of product management for ABB Robotics. “Predicting the braking behavior of a robot with its payload will help system integrators and end users save time and costs, with up to 25% reduction in the footprint when it comes to designing and building a robot cell or setting up a safety zone. This will help our customers optimize their processes and get the most out of their automation solutions." Learn more at
